CNJ series GEL battery utilizes AGM and gel mixed technology, componsed of strong grids, high purity lead and  fumed silica Gel electrolyte with good cycle life and wide temperature range performance. The unique plate design of the HUAFU CNJ series gel battery provides excellent frequent cyclic discharge performance. Patented structure design and focused on energy storage batteries with 30 years' experience, CNJ series achieve a cost effective product and widely used in different solar and wind system, lighting system, marine & RV energy storage parts.


6-CNJ-100 is one model of our CNJ series battery. It's a type of rechargeable maintenance free Valve Regulated sealed gel battery and designed for energy storage application, cycle use. The 12V200Ah @10hr battery provides the excellent characteristic for the wide range application of wind/solar system, off-grid home system, solar/wind lighting system and other energy storage filed.




Battery Construction:
1). Electrolyte: Be immobilized in the cell through the use of fumed silica gel agent or absorbed in the separators and plates. The cells shall have no residual free or bulk liquid electrolyte.
2). Lead : high purity lead, >99.996%
3). Separators: Made of fiberglass. Be porous to electrolyte but electrically insulating.
4). Container & Cover: containers and covers shall be made of a high impact, flame-retardant ABS plastic
5). Terminal: Terminal posts shall be cast in lead or lead alloy and have a copper core insert.
6). Valve: The valve operate at the pressure limits specified. The valve will not allow ingress of outside air into the unit.

Battery Specification:




Battery Feature:
1). Absorbent Glass Mat (AGM) technology for superior performance
2). Valve regulated, spill proof construction allows safe peration in any position
3). Power/volume ratio yielding unrivaled energy density
4). Rugged impact resistant ABS case and cover (UL94-HB)
5). Integrated ABS carrying handles for easy of movement
6). U.L. CE. IEC. SGS. RoHS. ISO9001. ISO14001. OHSAS18001-2007 recognized
7). Maintenance-free operation - no addition of water to the electrolyte is required.
8). Wide range of operating temperatures with temperature compensated charging.
9). Computer designed lead, calcium tin alloy grid for high power density.
10). Extended service life due to low self-discharge levels.

Battery Application
Off grid solar system, Solar street light, Solar/wind power station, Solar traffic light, Solar building system, inverter system, power station, and other energy strorage application etc.


Package and delivery:
in carton box and packed into export plywood case.   Packing data for 20GP FCL
